Bitmaps tags store textures used for the environment, objects, cube maps, sprites, effects, menus, and more. Don't be confused by the name; this is not a .bmp file and it cannot be directly opened in image editing software. The purpose of the tag is to store metadata about a texture and its image data, possibly compressed in a format like DXT1, ready for the engine and GPU to use. It can also store multiple images in a single tag.

Basics

To store textures and images in maps we use bitmap tags. Bitmap tags on their simplest are compiled from a .tif file in your data directory.

Tool Commands

tool bitmap <source-file>

This command is to import a single .tif file from your data folder and convert it into a bitmap the respective tags folder.

Example: You have a file named bar.tif in your data folder under data\foo\bitmaps

The tool command you would use would be:

tool bitmap "foo\bar\bitmaps\bar"

That would output the file tags\foo\bitmaps\bar.bitmap

tool bitmaps <source-folder>

This command is to import all .tif files in a data folder into the respective tags folder.

Example: You have foo.tif and bar.tif under data\example\bitmaps

The tool command you would use would be:

tool bitmaps "example\bitmaps"

That would output .bitmap versions of these files in the respective tags folder under example\bitmaps

Type

The bitmap type drop down box is used to tell tool how to process the image and what rules to apply.

  • 2D Textures: A flat 2D texture. Mainly used for environments, objects. Also used for huds and effects.
  • 3D Textures: A set of texture slices that when combined forms a texture cube. Used in the shader_transparent_plasma tag type.
  • Cube maps: A set of 6 textures that combines into a cube. Used for simulating reflections in shaders.
  • Sprites: A set of textures that have multiple sprites fitted on them. Used for effects and huds.
  • Interface bitmaps: Textures that don't have to follow the rule of needing to be power-of-two. It should only be used for menus.

Format

The format of the bitmap determines what way it will be stored, how big the bitmap file ends up being in a map file and how it ends up looking.

Compressed with color-key transparency

The smallest format the game supports, it's about 12.5% of the size in memory as a 32-bit bitmap. It uses DXT1 as an internal compression format. This means that for every 4x4 grid of pixels it picks two colors to store and at runtime these two colors are interpolated with two more colors. This works well for most textures, except normal maps which can end up making shaders look blocky because of the delicacy of the data stored in them.

This format does not support alphas and transparency very well. The alpha for each pixel can only be either 100% (white) or 0% (black). It also makes the colors on the texture black when the alpha is 0%.

Compressed with explicit alpha

At 25% the size of an equally sized 32-bit bitmap this format is mostly the same as color-key, with the only difference being that the image can now store an alpha. The internal format is DXT3 which means that the alpha uses 4-bit color, allowing for 16 different shades of brightness (Compared to the 256 levels for 32-bit).

The fact that this format stores the alpha in explicit values means it is good for noisy alphas with greatly differing brightness values for each pixel.

Compressed with interpolated alpha

Also at 25% of the size of a 32-bit bitmap this format provides an alternative way to store the alpha from explicit. The internal format is DXT5, which means the alpha is stored in a similar way to how the colors are stored. When compiling the bitmap tool finds the highest and lowest values in a 4x4 pixel grid, stores those and then at runtime the game interpolates it with two more values.

The alpha can have great color depth in terms of shades, which is really useful for situations where alpha brightness matters, but in situations where there is great varying brightness between pixels block artifacts can show up.

16-bit color

This format is 50% the size of a 32-bit bitmap. This format has a few different internal formats which can greatly affect the outcome of how the texture looks. The internal formats are r5g6g5, a1b5g5b5, and a4b4g4b4. Each of these formats is named after how many bits per pixel is allocated for each channel. For the depth of the channel you can do shades=2^bits.

32-bit color

As the biggest size for bitmap formats 32-bit (Also referred to as true color) bitmaps store their colors at the same settings as most consumer monitors. The internal formats are a8r8g8b8 and x8r8g8b8, the only difference between these is that in x8r8g8b8 the 8 bits that would store the alpha in a8r8g8b8 are ignored.

Monochrome

Using 25% of the size of a 32-bit bitmap this format was mainly used for huds in the xbox version of the game. This format does not function properly anymore on the PC version and Custom Edition of the game, but does work again in MCC.

High-quality compression

This is a new format (BC7) added to H1A MCC in 2023 which provides both high quality and good compression. You can read more about BC7 here.

Notes

When importing TIF file using tool with the format set to a compressed one tool might make the bitmap it outputs more noisy than it needs to be. It is speculated that this is because of a broken DXT toolkit being used in tool. Using other programs like Mozzarilla you can import DXT1,2,3 at higher qualities without increasing memory footprint.

Usage

The usage fields are used to enable special processing onto the bitmap.

Default

A default bitmap with normal mipmaps

Alpha Blend

This makes pixels that have 0 alpha turn black in the smaller (mipmap) versions of the texture. This is to prevent color bleeding on transparent images.

Height map

This will try to convert your source image into a normal map based on the brightness of the pixels. For this setting you need to set a height to get a proper output. This setting also converts the bitmap to a special 8-bit palletized format specifically designed for normal maps. Sadly this format does not render properly in the PC and Custom Edition versions of the game, only on Xbox. To be able to use this format you need to enable the flag "disable height map compression", which turns it into a normal 32-bit bitmap, but still with the lower color detail.

Using this is not recommended as generating your own normal map from a height map in a program like Photoshop will get you much better results.

Detail map

When setting the usage to detail map, tool will fade the bitmap to grey in every mipmap, this is so that when you are further away things that use the detail map won't look as noisy. The alpha fades to white.

You can modify how quickly the mipmaps fade to grey by editing "detail fade factor" under "post-processing". 0 means that it will slowly fade to grey until the last mipmap, and 1 means that the first and every subsequent mipmap is grey.

Light map

This is the setting used when tool or sapien generates a lightmap, you should not use this when importing normal bitmaps.

Vector map

Used mostly for special effects this setting stores the rgb channels as directional XYZ vectors, the alpha is left unmodified

2D Textures

2D textures are flat textures used in 3D environments, on objects, huds and effects. Bitmaps can hold one or more 2D textures either as permutations or animated textures.

Importing

2D textures can be imported from source images without extra borders around them, but when compiling multiple into one bitmap you will need to add them following the same rules as for sprites. 2D textures are required to be power-of-two.

3D Textures

3D textures are sets of textures (slices) that make up a solid 3D cube. They are only used in shader_transparent_plasma tags, which are used for the energy shield effect for instance.

Importing

3D textures need to be imported the same way as you import a sprite sheet, all slices should be put next to each other horizontally. Preferably you want to have the same amount of slices as the height and width of each slice. So if each slice is 64x64, you want 64 slices to make it into a 64x64x64 cube.

Cube maps

Cube maps are a combination of 6 textures that form one cube. It is used for reflections in shaders.

Importing

Cube maps are imported either as folded out cubes or sprite sheets. All faces should have the same resolution, power-of-two and square. Just like sprites, cube map bitmaps can contain multiple sequences/cube maps for use with forced permutations.

NOTE: Having multiple cube maps in one bitmap does not randomize them.

Examples of acceptable source images for cube map import:

UnfoldedSprite SequenceMultiple in one tag

Sprites

The sprite type allows a bitmap to contain a non-power-of-two texture, with support for animations with multiple permutations (sequences). Sprites are typically used for particles.

Color Plate

Scaled 10xOriginal Size

The color plate is the first 3 top-left pixels of the source file. It tells tool which colors are being used for the sprite borders (background), sequence dividers, and dummy space, respectively. Any colors may be used, as long as they aren't used in the sprites themselves.

If no color plate is defined, AKA: there is nothing in the left top. You have to use the default color for sprite borders (pure blue #0000FF), sequence dividers cannot be clearly defined, and you cannot use dummy space.

NOTE: The plate is not allowed to touch the sprites, but is allowed to touch sequence dividers.

Sprite borders

Sprites must be surrounded by a rectangular border of solid color. Any color may be used for the border as long as it isn't used in any of the sprites. This color should be the exact same as the first pixel of the color plate, or pure blue (#0000FF) if there is no color plate.

Any amount of padding may be used as long as the sprite is isolated by at least a one pixel border. Individual sprites also don't need to be perfectly lined up.

Budget

Budget size determines how big each texture page is (and thus how many sprites will appear on each page). Budget count sets how many texture pages there will be. Both of these values should be set for sprites.

When compiling a bitmap, tool will output how many pages were generated and the percentage of space filled by the sprites. Budget size and count should be tweaked to get this percentage as high as possible, as unused space is wasted memory.

Budget sizes are limited to "square" dimensions like 256x256 and 512x512. Because of this, it is sometimes more memory efficient to split the sprites up across several pages. For example, putting a sprite sheet with seven 56x56 sprites on a single page would require a 512x512 budget size, because 512x512 is the smallest size that can fit all of the sprites. However, If that same sprite sheet was split up across two pages, each page would only need to be 256x256, cutting memory usage in half.

NOTE: Tool automatically uses at least 4 pixels of padding between each sprite. (This is so that there will always be at least one pixel of space between different sprites in all mipmaps, as tool also uses a default mipmap count of 2 for these. 4 -> 2 -> 1.) This means four 32x32 sprites will for instance not fit on a 64x64 page. Make sure to take this into account when choosing a budget size!

Sequences

A sprite sheet with multiple sequences. Frames are lined up horizontally, and permutations are stacked vertically. Note the magenta line separating each sequence. A sequence is an animated sprite. Each sprite in a sequence represents a "frame" of the sprite's animation. A bitmap may contain multiple sequences, which allows for random and forced permutations. Each frame of a sequence is lined up left-to-right. Each sequence permutation is stacked vertically, top-to-bottom.

If the source file has more than one sequence, each sequence should also have a sequence divider above it. A sequence divider is a straight line of solid color (using the color plate's second pixel's color) at least one pixel wide that spans the entire width of the image. The divider must be a different color than the sprite border. The sequence divider may be left out if the file only has one sequence or if it has no color plate.

TIP: Mozzarilla is a good tool for viewing sequences.

NOTE: All sprites in a sequence must be the same size.

NOTE: Tool will sometimes split a sequence across several pages. This does not affect functionality.

QUIRK: Only the start of a sequence divider needs to be the color defined on the color plate. After that it can be any color, or could even just end prematurely.

Dummy Space

Space usage on a sprite with dummy space vs without.

Dummy space is space that is counted toward the size and position of your sprite, but not included in the data of the sprite in the bitmap. This is useful for two reasons: It allows a sprite that's smaller than other sprites in a sequence, and it tells tool how to center the smaller sprite without bulking up the file size with padding. Dummy space must be a solid color that is different from the sprite border and sequence separator colors.

Sprite Usage

Under "... more sprite processing" there is a drop down box that controls the background color of the texture page. This is used to avoid color bleeding in from outside the sprite boundaries at runtime and creating outline-like artifacts.

  • blend/add/subtract/max: Makes the background black.
  • multiply/min: Makes the background white.
  • double multiply: Makes the background grey (50% grey).

Interface bitmaps

Interface bitmaps are textures that do not need to follow the power-of-two rule. They are used for menus (Not huds) and should never be used for anything else. They also generate without mipmaps and need to be 32-bit.

Mipmap count

Under "miscellaneous" there is a setting for how many mipmaps you want in your bitmap. This is useful if you wish to limit the mipmap levels, or remove them entirely.

0 defaults to all mipmaps, 1 is only the biggest mipmap, etc.

Tool Errors and Warnings

Errors that are known and suggestions on how to fix them.

--> !!WARNING!! failed to open TIFF: file does not exist <--

CauseFix
The file is not where you told tool it isMake sure the file is somewhere in data or a subfolder and check your spelling of the path.
The file is a TIFF file and not a TIF filesave as a .TIF file; legacy Tool doesn't understand .TIFF for some reason, but it does understand TIF. No longer true in MCC Tool.

Unknown data compression algoritm # (0x#). --> !!WARNING!! failed to open TIFF: not a TIFF file <--

  • Cause: Your TIF file might be using a new algoritm that is not supported by tool
  • Fix: try saving it with a different program or with different settings.
  • Info: (Tool uses a version of libtiff from 2002/07/30, so it will not understand a lot of the new tiff specifications.

skipping bitmap with non-power-of-two dimensions

  • Cause: Your source tif does not follow the power of two rule.
  • Fix: Make sure your source image has a resolution that can be divided by 2 without ending in a decimal. 2x2, 4x4, 8x8, 16x16, 32x32, 64x64, 128x128, 256x256, 512x512, 1024x1024, 2048x2048.
  • Alternative fix: If you are intending to make a sprite sheet or an interface bitmap, ignore this and set the type to the correct value in the .bitmap file, save, and put in the tool command again.

### ERROR can't extract sprites without a valid plate

CauseFix
You didn't add the three color plate pixels in the top-left corner of the source file.Add the color plate
You have bitmaps of different size in a sequence.Use dummy space to pad the smaller sprites to match the bigger ones.
One of your sprites is touching the plate.Move the sprite away from the plate by at least one pixel.

### ERROR one or more sprites do not fit in the requested page size

CauseFix
The sprite page is too small to contain the sprite sheet; not all bitmaps are processed if any.Set a bigger page size in the bitmap tag.
A sequence divider has been interpreted as a sprite.Make sure your plate pixel that indicates the color of the dividers has the exact same color as the dividers.

Reminder: Every sprite is padded with 4 pixels on each border, so while your sprites may fit in theory, they may not in practice.

sprite budget met ( 0%)

  • Cause: Tool is reading your source file, but not actually finding any textures.
  • Fix: Verify your color plate is set up correctly, and each sprite is properly isolated with border color.

==> !!WARNING!! bitmap with greater than 1-bit alpha being compressed as DXT1 <==

  • Cause: You're compiling a source file that has a detailed alpha map into a bitmap with color key transparency.
  • Fix: You could ignore this, but chances are the alpha was important. Use interpolated or explicit alpha instead.

### WARNING no sprite budget set

  • Cause: "sprite budget count" is not set in the bitmap tag
  • Effect: Tool picks a size for you, and you're probably not going to like it.
  • Fix: set the sprite budget count

Structure and fields

FieldTypeComments
typeenum
OptionValueComments
2d textures0x0
3d textures0x1

Used for shader_transparent_plasma noise maps.

cube maps0x2
sprites0x3
interface bitmaps0x4
encoding formatenum

Format to use when generating the tag

OptionValueComments
dxt10x0
dxt30x1
dxt50x2
16-bit0x3
32-bit0x4
monochrome0x5
  • H1X only
  • H1A only

This format is only supported on Xbox and MCC. Using this format can significantly reduce tag size for monochromatic bitmaps.

high-quality compression0x6
  • H1A only

BC7 is a new compression format supported in MCC. It allows each compressed block of pixels to be encoded with a different allocation of bits per channel, providing good compression and maintaining a high quality.

usageenum
OptionValueComments
alpha blend0x0
default0x1
height map0x2
detail map0x3
light map0x4
vector map0x5
flagsbitfield
FlagMaskComments
enable diffusion dithering0x1
disable height map compression0x2
uniform sprite sequences0x4
filthy sprite bug fix0x8
hud scale 0.50x10
invert detail fade0x20
use average color for detail fade0x40

When bitmap usage is detail map, mipmaps will fade to the average colour of the bitmap when importing. Otherwise it will fade to gray. Prior to this flag being added in December 2022, the H1 MCC mod tools would fade to average colour by default like Halo 2.

detail fade factorfloat
  • Min: 0
  • Max: 1
sharpen amountfloat
  • Min: 0
  • Max: 1
bump heightfloat
  • Unit: repeats
sprite budget sizeenum
OptionValueComments
32x320x0
64x640x1
128x1280x2
256x2560x3
512x5120x4
1024x10240x5
2048x20480x6
sprite budget countuint16
color plate widthuint16
  • Non-cached
  • Unit: pixels
  • Volatile
  • Read-only
color plate heightuint16
  • Non-cached
  • Unit: pixels
  • Volatile
  • Read-only
compressed color plate dataTagDataOffset
  • Non-cached
  • Volatile
  • Read-only

Contains the original raw source data used to compile this bitmap tag, if available. Bitmap tags which have been extracted from cache files will not have this data.

FieldTypeComments
sizeuint32
externaluint32
file offsetuint32
pointerptr64
processed pixel dataTagDataOffset?
  • Non-cached
  • Read-only
blur filter sizefloat
  • Unit: pixels
  • Min: 0
  • Max: 10
alpha biasfloat
  • Min: -1
  • Max: 1
mipmap countuint16
sprite usageenum
OptionValueComments
blend add subtract max0x0
multiply min0x1
double multiply0x2
sprite spacinguint16
  • Read-only
bitmap group sequenceBlock
  • HEK max count: 256
  • Max: 65534
  • Read-only
  • Read-only
FieldTypeComments
nameTagString
first bitmap indexuint16
bitmap countuint16
spritesBlock
  • HEK max count: 64
  • Max: 65534
  • Read-only
FieldTypeComments
bitmap indexuint16
leftfloat
rightfloat
topfloat
bottomfloat
registration pointPoint2D
FieldTypeComments
xfloat
yfloat
bitmap dataBlock
  • HEK max count: 2048
  • Max: 65534
  • Read-only
  • Read-only
  • Processed during compile
FieldTypeComments
bitmap classenum
  • Hidden
OptionValueComments
none0xFFFFFFFF
null0x0
actor0x61637472
actor variant0x61637476
antenna0x616E7421
model animations0x616E7472
biped0x62697064
bitmap0x6269746D
spheroid0x626F6F6D
continuous damage effect0x63646D67
model collision geometry0x636F6C6C
color table0x636F6C6F
contrail0x636F6E74
device control0x6374726C
decal0x64656361
ui widget definition0x44654C61
input device defaults0x64657663
device0x64657669
detail object collection0x646F6263
effect0x65666665
equipment0x65716970
flag0x666C6167
fog0x666F6720
font0x666F6E74
material effects0x666F6F74
garbage0x67617262
glow0x676C7721
grenade hud interface0x67726869
hud message text0x686D7420
hud number0x68756423
hud globals0x68756467
item0x6974656D
item collection0x69746D63
damage effect0x6A707421
lens flare0x6C656E73
lightning0x656C6563
device light fixture0x6C696669
light0x6C696768
sound looping0x6C736E64
device machine0x6D616368
globals0x6D617467
meter0x6D657472
light volume0x6D677332
gbxmodel0x6D6F6432
model0x6D6F6465
multiplayer scenario description0x6D706C79
preferences network game0x6E677072
object0x6F626A65
particle0x70617274
particle system0x7063746C
physics0x70687973
placeholder0x706C6163
point physics0x70706879
projectile0x70726F6A
weather particle system0x7261696E
scenario structure bsp0x73627370
scenery0x7363656E
shader transparent chicago extended0x73636578
shader transparent chicago0x73636869
scenario0x73636E72
shader environment0x73656E76
shader transparent glass0x73676C61
shader0x73686472
sky0x736B7920
shader transparent meter0x736D6574
sound0x736E6421
sound environment0x736E6465
shader model0x736F736F
shader transparent generic0x736F7472
ui widget collection0x536F756C
shader transparent plasma0x73706C61
sound scenery0x73736365
string list0x73747223
shader transparent water0x73776174
tag collection0x74616763
camera track0x7472616B
dialogue0x75646C67
unit hud interface0x756E6869
unit0x756E6974
unicode string list0x75737472
virtual keyboard0x76636B79
vehicle0x76656869
weapon0x77656170
wind0x77696E64
weapon hud interface0x77706869
invader bitmap0x65626974
  • Non-standard
invader scenario0x53636E72
  • Non-standard
invader sound0x65736E64
  • Non-standard
invader font0x6E666E74
  • Non-standard
invader ui widget definition0x6E757764
  • Non-standard
invader unit hud interface0x6E756869
  • Non-standard
invader weapon hud interface0x6E776869
  • Non-standard
shader transparent glsl0x7374676C
  • Non-standard
widthuint16
  • Unit: pixels
heightuint16
  • Unit: pixels
depthuint16
  • Unit: pixels
typeenum
OptionValueComments
2d texture0x0
3d texture0x1
cube map0x2
white0x3
formatenum
OptionValueComments
a80x0
y80x1
ay80x2
a8y80x3
unused10x4
unused20x5
r5g6b50x6
unused30x7
a1r5g5b50x8
a4r4g4b40x9
x8r8g8b80xA
a8r8g8b80xB
unused40xC
unused50xD
dxt10xE
dxt30xF
dxt50x10
p8 bump0x11

This format is only supported on Xbox and MCC.

bc70x12

This format is only supported on MCC.

flagsbitfield
FlagMaskComments
power of two dimensions0x1
compressed0x2
palettized0x4
swizzled0x8
linear0x10
v16u160x20
unused0x40
  • Cache only
make it actually work0x80
  • Cache only
external0x100
  • Cache only
stubbed0x200
  • Cache only
zstandard compressed (extended)0x400
registration pointPoint2DInt
FieldTypeComments
xint16
yint16
mipmap countuint16
pixel data offsetuint32
pixel data sizeuint32
  • Cache only
bitmap tag iduint32
  • Cache only
pointerptr32
  • Cache only

Acknowledgements

Thanks to the following individuals for their research or contributions to this topic:

  • gbMichelle (Information on formats, bitmap types, usage, compilation, and errors)
  • Jesse (Misc info)
  • Kavawuvi (Invader tag definitions)
  • Mimickal (Information on formats, bitmap types, usage, compilation, errors, sprite sheets, and proofreading)
  • MosesOfEgypt (Tag structure research)
